TracBal_V7.2_eSIM-MINI
The TracBal_V7.2_eSIM MINI is an intelligent geolocation terminal, dedicated to the non-motorized vehicles, equipped with GNSS and GSM connectivity, designed to gather device coordinates and transmit them to a server over the GSM network.
The device is equiped with a power connector, with which it can be charged via 12V.
Ce contenu sera partagé sur toutes les pages produits.
technical sheet
Product
|
Category |
Field |
Value |
|---|---|---|
|
Product |
Model name |
TracBai_V7.2 eSIM MINI |
Device Operation
|
Category |
Field |
Value |
|---|---|---|
|
Device operation |
Description |
The device collects in real-time the geographic coordinates (position, speed, timestamps, etc.), then it processes all the data collected, and after that, it sends them to the server via GSM. All the processed data can be visualised in a platform. |
Device Specifications
|
Category |
Field |
Value |
|---|---|---|
|
Device specifications |
Wireless communication |
4G LTE (Cat-1), 2G GSM/GPRS Multi Bands |
|
Device specifications |
GNSS tracking sensitivity |
-159.5 dBm |
|
Device specifications |
GNSS Hot start |
<1s |
|
Device specifications |
GNSS Cold start |
<40s |
|
Device specifications |
Location services |
GNSS (1559 - 1610 MHz) |
|
Device specifications |
Memory |
16MB internal flash memory |
|
Device specifications |
Sleep modes |
Modem sleep, light sleep, deep sleep, hibernation mode |
|
Device specifications |
Antennas placement |
Internal |
|
Device specifications |
GNSS Accuracy |
<2m |
|
Device specifications |
SIM |
eSIM |
Certifications
|
Category |
Field |
Value |
|---|---|---|
|
Certifications |
Supply voltage |
3.7V Battery |
|
Certifications |
Interfaces |
Bluetooth (BLE) Configuration, OTA Updates |
|
Certifications |
Indicator/Buttons |
RGB LED |
|
Certifications |
Configuration and firmware update |
Bluetooth (BLE) Configuration, OTA Updates |
|
Certifications |
Remote device configuration |
ProtoFlex: Dynamic adaptation of the communication protocol according to the usage context |
|
Certifications |
Remote device configuration |
Supported formats: JSON, XML, TXT (Flexible integration with various backend systems) |
|
Certifications |
Remote device configuration |
Fully customizable data frames according to specific requirements |
|
Certifications |
Battery |
3.7V 3000mAh Rechargeable Li polymer |
|
Certifications |
Battery life estimates |
4 to 7 Days |
Physical Characteristics
|
Category |
Field |
Value |
|---|---|---|
|
Physical Characteristics |
Enclosure Dimensions |
119mm (L) x 94mm (W) x 60mm (H) |
|
Physical Characteristics |
Ingress Protection Rating |
IP68 |
Features
|
Category |
Field |
Value |
|---|---|---|
|
Features |
Small case |
Easy to mount in small access areas |
|
Features |
RFID Protocol Standards |
Real time tracking |
|
Features |
Chip Storage Area |
Small case |
|
Features |
ShiftSync |
Automatic GPS activation only during scheduled working hours |
|
Features |
GeoTrigger |
GPS activation only when entering the designated work zone |
|
Features |
ActiveSleeper |
Enters sleep mode during periods of inactivity |
|
Features |
TurnTrack |
Sends GPS data only when a change in direction is detected |
|
Features |
FlexFormat |
Allows full customization of the GPS data output format (JSON, XML, CSV, etc.) |
|
Features |
FlexFormat |
Activates high-precision tracking mode for easy localization of a lost or stolen device |
|
Features |
GuideMe |
LED indicators to easily guide sweepers to their destinations or points of interest in real time |
|
Features |
QuickFlag |
Instant anomaly reporting with a single press of configurable buttons |
|
Features |
ProgressPulse |
Multicolor LED indicator showing real-time task completion rate |
|
Features |
PowerSaveSync |
Stores GPS data in internal memory when battery is low and transmits when recharged |
|
Features |
ProtoFlex |
Flexible configuration of data transmission protocols (HTTP(S), MQTT, TCP, etc.) |
|
Features |
Datarecall |
On-demand retrieval of GPS data stored in internal memory for audit/verification |
|
Features |
AdjustPro |
Full configuration of GPS parameters (frequency, acquisition rate, sleep modes, etc.) |
|
Features |
Omni-cloud |
Compatible with major cloud services (Azure, AWS, etc.) |
|
Features |
Omni-Connect |
Compatible with platforms (Geodaki, Wacomos, Geored, etc.) |
|
Features |
ConfigHub |
Mobile app for OTA configuration, activation, and deactivation |
|
Features |
ChargeBox |
Multi-device charging (wired & wireless options) |
