Sweep Tracker HST-EG01G
Smart Geolocation Terminal for Real-Time Tracking & Data Transmission
The Sweep Tracker HST-EG01G is an intelligent geolocation terminal, dedicated to the non-motorized vehicles, equipped with GNSS and GSM connectivity, designed to gather device coordinates and transmit them to a server over the GSM network.
The device is a 4G full Netcom vehicle positioning terminal carefully built for the Internet of Vehicles. Light sensor, ultra-low power and IP67 waterproof.
With strong magnetic, low power consumption, long standby time, Type-C interface power cord
Ce contenu sera partagé sur toutes les pages produits.
Technical sheet
Device Operation
|
Category |
Field |
Value |
|---|---|---|
|
Device operation |
Description |
The device is a 4G full Netcom vehicle positioning terminal carefully built for the Internet of Vehicles. Light sensor, ultra-low power and IP67 waterproof. With strong magnetic, low power consumption, long standby time, Type-C interface power cord |
Physical Specification
|
Category |
Field |
Value |
|---|---|---|
|
Physical Specification |
Dimensions |
L95W72H35 MM |
|
Physical Specification |
Weight |
70g |
Cellular
|
Category |
Field |
Value |
|---|---|---|
|
Cellular |
4G LTE Cat1 Bands |
LTE:B1/B2/B3/B4/B5/B7/B8/B20/B28/B34/B38/B39/B40/B41/B66 |
|
Cellular |
Data Transfer |
LTE: Max 10Mbps (DL) / Max 5Mbps (UL) |
|
Cellular |
Data Support |
SMS (TXT/PDU) |
Location Services
|
Category |
Field |
Value |
|---|---|---|
|
Location Services |
GNSS |
GPS, GLONASS, GALILEO, BEIDOU, AGPS, QZSS, SBAS |
|
Location Services |
Receiver |
64 Channel |
|
Location Services |
Tracking Sensitivity |
-160dB |
|
Location Services |
Position Accuracy |
<2.0m CEP |
|
Location Services |
Hot Start |
<1s |
|
Location Services |
Cold Start |
<30s |
Operating Environment
|
Category |
Field |
Value |
|---|---|---|
|
Operating Environment |
Operating Temperature |
-20°C to +75°C |
|
Operating Environment |
Storage Temperature |
-40°C to +85°C |
|
Operating Environment |
Operating Humidity |
5% to 95% non-condensing |
|
Operating Environment |
Ingress Protection Rating |
IP67 |
Interface
|
Category |
Field |
Value |
|---|---|---|
|
Interface |
GNSS Antenna |
Internal High Gain |
|
Interface |
Cellular Antenna |
Internal LTE High Gain |
|
Interface |
LED Indicator |
6 Status Led Light |
|
Interface |
Sim Card |
Micro-SIM |
|
Interface |
Memory |
Internal 4MB flash Memory |
Category |
Field |
Value |
|---|---|---|
|
Features |
Sensor |
Accelerometer 3D |
|
Features |
Scenarios |
Over speed detection |
|
Features |
Scenarios |
GPS tracking |
|
Features |
Scenarios |
History playback |
|
Features |
Scenarios |
Vibration detection |
|
Features |
Scenarios |
Light sensor detection |
|
Features |
Scenarios |
Geofence alarm |
|
Features |
Scenarios |
SOS alarm |
|
Features |
Sleep Modes |
Online / Sleep / Normal |
|
Features |
GPRS Commands |
Configuration OTA |
Category |
Field |
Value |
|---|---|---|
|
Power |
Battery |
7500mA / 3.7V lithium battery |
|
Power |
Power consumption |
3.7V:<800uA (OnlineSleep) / 3.7V:<24mA (Normal) |
